KIOSK ENCLOSURE

Available in many eye-catching colors and finishes

High security extra tough lock

Integrated stereo speakers

Door open detector for added security

Rugged 14 gauge metal

Safe box open detector limiting fraud

DISPLAY MODULE

17" TFT active matrix LCD XGA (1024 x 768), 250 nit

4mm or 6mm tempered protective glass overlay

Touch screen

SAW (Surface Acoustic Wave)

IR (Infrared)

OPTIONAL SECONDARY DISPLAY

19" TFT active matrix LCD SXGA (1280x1024), 250 nits or 32" LCD (1366x768)

Tamper-proof protective glass

Easy to maintain and update content

Vandal resistant protecting life of screen

Designed for public access with ruggedized enclosure

OPTIONAL HARDWARE ACCESSORIES

Multiple card readers (smart, chip and 3 Mag stripe)

Coin and Bill acceptor (multiple currencies)

Rugged keyboard with trackball

Video camera

POTS, xDSL, Wireless, WiFi, ISDN, Cellular

Thermal printers: 3", 8.5", ticket printer

Barcode scanner (omni-directional)

Microphone

Uninterruptible power supply

Fingerprint scanner

Telephone handset magnetic On/Off

Pin pad (debit, access and credit)

EMV2 credit card / pin pad

Business card and license scanner

KING CORE COMPUTING MODULE

1.6 GHz Intel® Processor (up to 2.4GHz Core 2 Duo)

Socket 775 Motherboard or equivalent, up to 1066 MHz FSB

10/100 Ethernet

512 MB RAM (up to 2 GB)

40GB HD (options available)

Solid state IDE HD option

Connectivity: PCI Slots, USB ports, 5 COM ports

Stereo sound with hardware volume control

3D graphics controller with up to 128 MB on board video

AGP 8x slot

Air inlet with filter to minimize dust

Thermodynamically designed improving lifecycle

Software watchdog

Hardware watchdog

Programmable relays

Line reversal and pulse detection
